Home > Product
CSDT-52300_CSDT-52301
Basic information
1.Triple digit  display .
2.0.52 Inch.
3.Case mold type.
4.Low power consumption.
5.Various color.
Featured Benefits
Contact us
Product specifications
Package Outer Dimensions (mm) Color Part Number Dominant Wavelength λd (nm) Luminous Intensity IV (mcd) Forward Current IF (mA)
Common Anode Common Cathode Min. Typ.
0.52 inch 37.9*17.6*7 Green CSDT-523002 CSDT-523012 525 110 200 10
0.52 inch 37.9*17.6*7 Green CSDT-52300M CSDT-52301M 570 6 10 10
0.52 inch 37.9*17.6*7 Yellow CSDT-52300T CSDT-52301T 590 20 43 10
0.52 inch 37.9*17.6*7 Orange CSDT-52300A CSDT-52301A 605 20 55 10
0.52 inch 37.9*17.6*7 Red CSDT-52300V CSDT-52301V 625 17 30 10
0.52 inch 37.9*17.6*7 Red CSDT-52300L CSDT-52301L 630 17 30 10
0.52 inch 37.9*17.6*7 Red CSDT-52300U CSDT-52301U 645 8 15 10
File Download
